The 4-20 mA output signal of the DPI sensors, which is supplied by the two-wire transmitter, can be processed in all common industrial control systems and does not need to be calibrated when the sensor is connected. The output signal for pressure and temperature measurement of the DPI+T sensors is a 0-10 V signal each and can be processed in all common industrial controls. When the sensor is connected, it does not need to be calibrated.
The sensor DPI requires a power supply of 12.5-30 VDC.
The sensor DPI+T requires a power supply of 16.6-30 VDC.
DPS (0.5-3.5 V / 5 VDC)
The output signal for pressure and temperature measurement of the DPS sensors is a 0.5-3.5 V ratiometric signal for pressure measurement and a 0.5-4.1 V ratiometric signal for temperature measurement and can be processed in all common industrial control systems. When connecting the sensor it does not need to be calibrated.
The DPS sensor requires a power supply of 5 VDC ± 5 %.
DPS11 (4-20mA / 12-30 VDC)
The 4-20 mA output signal of the DPS11 sensors, which is supplied by the two-wire transmitter, can be processed in all common industrial control systems and does not need to be calibrated when the sensor is connected.
The sensor DPS11 requires a power supply of 12-30 VDC.
